Cov tsoos dyeing thiab luam ntawv mills tawm tsam nrog lub peev xwm tsis txaus, tsis muaj peev xwm tuav cov xaj me me, thiab phaj siab- ua cov nqi?
Xaiv DGE32 Lub taub hau Textile Digital tshuab luam ntawv. Rov qab los ntawm ntau xyoo ntawm kev paub hauv kev luam ntawv thiab dyeing cov cuab yeej tsim khoom, cov cuab yeej siv tshuab paub tab, cov txheej txheem tswj hwm saum toj kawg nkaus, thiab kev xaiv dual-brand printhead, nws ua rau cov mills ib txwm ua kom tau txais cov nqi qis dua digital hloov pauv - txeeb lub sijhawm digital luam ntawv, ua raws li kev txiav txim ntawm txhua qhov ntau thiab tsawg, thiab yooj yim txhawb koj lub Hoobkas kev sib tw.
|
|
|
|
| Printhead | Controllable Temperature Ink Station Ink Circuit Court System | Tshwj xeeb sab -mounted welded- koom nrog lub ntsiab nqaj |
Core Zoo
●32-Printhead Array + 8-Xim Channel rau Full-Gamut Printing
Cov tshuab luam ntawv digitalnta ib 32-printhead array nrog 8 ywj siab xim raws, xa tag nrho-gamut luam ntawv. Peb caug-ob lub taub hau kev lag luam ua haujlwm sib luag, thiab 8-channel system rov tsim cov qauv zoo nrog cov ntsiab lus tshwj xeeb.
Nws txhawb nqa ob hom kev xaiv: 1-pass high-speed ntau lawm thiab 2-pass high-txhais luam ntawv, sib npaug ntawm cov khoom siv thiab luam tawm kom tau raws li ob qho tib si ntau lawm thiab high-end customization xav tau.
●Optional Dual-Brand Industrial Printheads: Kyocera / Ricoh
CovNpuag Digital Printertuaj yeem nruab nrog Kyocera lossis Ricoh industrial printheads raws li koj cov peev nyiaj thiab kev tsim khoom. Xaiv tus nqi tsim nyog Kyocera lub taub hau rau kev tsim khoom loj, lossis xaiv Ricoh taub hau rau kev ua haujlwm siab, qib qib qib luam ntawv- hloov pauv tus nqi tswj uas sib npaug ntawm lub peev xwm thiab qhov zoo.
● Huichuan Tswj System
Lub tshuab tag nrho yog siv los ntawm Huichuan tus thawj tswj kev lag luam, kev cai tsim rau cov khoom siv luam ntawv. Nws muaj cov lus teb ceev ceev thiab kev ua haujlwm siab, ua kom muaj kev sib koom ua ke ntawm tus number case los ntawm tag nrho 32 printheads, carriage txav, thiab siv conveying hauv kev ua haujlwm siab.
|
|
|
Brand Development History
DGE tau koom tes nrog kev lag luam textile printing thiab dyeing machinery kev lag luam rau ze li 30 xyoo. Nws yog ib qho ntawm Tuam Tshoj cov tuam txhab tsim ua ntej tshaj plaws rau R & D thiab tsim cov tshuab luam ntawv teb-screen.
Thawj theem:Tsom ntsoov rau R&D thiab kev tsim cov tshuab luam ntawv rotary-screen, tau txais cov lus txib zoo ntawm cov thev naus laus zis hauv qab- suav nrog cov qauv siv tshuab, kev xa cov ntaub, kev tswj nruj, thiab tshuab ziab khaub ncaws. Ua haujlwm ntau txhiab lub tshuab luam ntawv thoob plaws Suav teb, Dego tau txais kev nkag siab tob rau hauv cov ntsiab lus mob ntawm cov tsoos dyeing thiab luam ntawv ntau lawm thiab lub ntiaj teb xav tau ntawm cov chaw ua haujlwm pem hauv ntej.
Transformation & Upgrading Theem:Ua kom nrawm nrog kev hloov pauv digital yoj hauv kev lag luam textile, thiab txhim kho xyoo ntawm kev siv tshuab R & D kev paub hauv cov khoom siv luam ntawv, DGE tau nkag mus raucov cuab yeej luam ntawv digitalsector. Cov thev naus laus zis tseem ceeb los ntawm cov tshuab ua teb-screen- xws li kev tswj kev siv zog, kev co damping, thiab cov ntaub ntawv qhia - tau seamlessly xa mus rau cov khoom siv luam ntawv.
Theem tam sim no:Tam sim no DGE tau ua tiav ib txoj kab ob txoj kab uas suav nrog ob qho tib si cov khoom siv rotary-screen thiab cov cuab yeej luam ntawv qib siab kawg. Nws nkag siab txog tus cwj pwm tsim khoom ntawm cov tsoos dyeing thiab luam ntawv mills thaum tseem paub txog cov kev tswj xyuas ntse ntawm digital printing- muab cov kev daws teeb meem uas txuas rau cov qub thiab tshiab
Xaiv DGE - xaiv ruaj khov, ua haujlwm tau zoo, thiab muaj txiaj ntsig kev lag luam digital luam ntawv tsim tau.
Cim npe nrov: Tuam Tshoj 32 lub taub hau textile digital tshuab luam ntawv manufacturers, lwm tus neeg, Hoobkas
| Cov khoom npe | 32 Lub taub hau Textile Digital tshuab luam ntawv | ||||
| Khoom qauv | DGE-M929-200 | DGE-M929-240 | DGE-M929-280 | DGE-M929-340 | |
|
Sau taub hau |
Hom | Japanese tshuab luam ntawv taub hau Ricoh Printheads | |||
| Kev npaj | 4×8 | ||||
| Ntim / Xim | 32 lub taub hau / 8 xim | ||||
| Txoj siv sia | Habasit | ||||
| Max luam ntawv dav | 1850 hli | 2250 hli | 2 650mm | 3 250mm | |
|
Tshuab ceev (8 xim hom) |
1 dhau | 1100m²/h | 1300m²/h | 1500m²/h | 1700m²/h |
| 2 dhau | 600m²/h | 700m²/h | 800m²/h | 900m²/h | |
| 3 dhau | 280m²/h | 350m²/h | 450m³/h | 600m²/h | |
|
Tau tshaj tus number case |
Hom cwj mem | Txheej, nquag number case, siab -kub dispersion, acidity | |||
| Xim xim | Cyan C, magenta M, Daj Y, Dub K, Txiv kab ntxwv O, Ci liab R, Sapphire xiav B, Ntsuab G; xaiv tau LM, LC, LK | ||||
| Cov ntawv luam tawm | Paj rwb, linen, silk, wool, tshuaj fibers, blends thiab ntau yam tshiab fiber ntau woven thiab knitted fabrics | ||||
| Software | Spanish RlP software | ||||
| Hom duab | Cov ntaub ntawv hom: TIF / JPG / EPS / PDF, xim qauv: RGB / CMYK | ||||
| Kev xa cov ntaub ntawv | Gigabit fiber ntau / USB 3.0 | ||||
|
Muaj nuj nqi |
Fabric feeding system |
Tsis siv neeg tas li nro pub Knitted (elastic) npuag pub system Adjustable Tension Warp Separation thiab Fabric Feeding System Movable siab cov menyuam |
|||
|
Sau taub hau Qhov siab |
2 ~ 30mm (Adjustable) | ||||
|
Npuag kom qhuav |
Kub cua tshuab ziab khaub ncaws | ||||
| ink muab system | Muaj -qib tsis zoo siab degassing number case mov, luam lub taub hau number case hauv kev ua haujlwm | ||||
| Intelligent ntxuav | Tsis siv neeg tu thiab tsis siv neeg noo noo khaws cia | ||||
| Ntxuav qhov system |
Muab ob npaug - txhuam cov menyuam, Ob chav huv cov menyuam, Muab ob npaug rau- txheej sponge, Ntse Sprinkler, Dej- tshem riam phom, ziab ntau ntau Cov pas nrig sib nqus sau dej |
||||
| Ua haujlwm ib puag ncig | Fais fab mov | 380VAC ± 5%, (Peb-theem tsib-wire system), 50HZ | |||
| Hwj chim | Printing system: 20KW (Heating system): 20-80KW | ||||
| Cua siab | 6 ~ 8Mpa (kev hloov kho) | ||||
| Kub thiab av noo |
Ambient kub: Pom zoo 25-30 degree Ambient humidity: Pom zoo 60-80% |
||||
| Dimension | Tshuab loj (mm) | 5000*5600*2450 | 5000*6000*2450 | 5000*6400*2450 | 5000*6800*2450 |
